The L801 High-Performance Film Shrink Packaging Machine is engineered for modern food manufacturers seeking uncompromised efficiency and environmental responsibility. This automatic, high-speed solution integrates sealing, wrapping, and shrink-tunnel processing into a single streamlined system, optimized for cup noodles production lines.With a maximum packaging speed of 100 packs/minute and a compact footprint, it balances rapid output with space-efficient design.
Model | LB-801 | LB-802 | LB-803 |
Machine Szie LxWxH(mm) | 1510×1380×1230 | 2000×1670×1325 | 2430×1965×1325 |
Packing size LxWxH(mm) | (50~400) X (50~280) X (2~150) | (100~560) X (60~430) X (10~220) | (200-830) X (200~630) X (10~220) |
Sealing bars size LxW(mm) | 450×335 | 630×520 | 900×700 |
Maximum Films Width (inches) | 22" | 27" | 38" |
Power | 220V, 1P, 2.5Kw | 220V, 1P, 3.5Kw | 220V, 1P, 4Kw |
Packing capacity (packs/min) Depends on products. | Max. 40 | ||
Pneumatic (NI/min) | 60 (6bar) | 80 (8bar) | 80 (8bar) |
Equipped with precision sealing bars and a programmable shrink tunnel, the L801 ensures airtight, wrinkle-free packaging. The tunnel’s intelligent temperature control (380V, 28kW) delivers uniform shrinkage across diverse film types—PVC, POF, PE, and PET—while consuming 12 kW operating power to minimize energy use.
Intuitive Control Panel: A touchscreen with multilingual support simplifies parameter adjustments (speed, temperature, seal time) and real-time process monitoring.
Safety First: Emergency stops, over-temperature protection, and interlocked guards ensure operator safety.
Quick Changeovers: Tool-less adjustments for film rolls and sealing bars minimize setup time, supporting agile production shifts.
• Consistent sealing process
• Pillars drive design provides excellent stability and durability
• Seal seam is neat and fix without fold line
• Automatic film advance system
• Two sets of photoelectric sensor system automatically compensate for package length change
• Tool-less change over with scaled adjustments throughout
• Different brands of shrink film is acceptable
• LB-801 is mainly designed for packing thin and tiny product
• LB-801 and LB-802 is equipped with kissing conveyor
The L801 isn’t just a machine—it’s a strategic asset for brands prioritizing speed, sustainability, and shelf-ready appeal.Elevate your cup noodles packaging to meet consumer demand for eco-conscious convenience while boosting ROI through energy savings and reduced material waste.
